Mode-locking device

Five fulcrum toggle mechanism by advanced computer optimization, and finite element analysis to guide the best structural design, to ensure the rigidity and strength of the clamping mechanism, the unique moving plate roller mechanism to ensure the balance and quiet operation of the mechanism, built-in mechanical safety mechanism, no adjustment, high safety, complete lubrication system to protect the accuracy and life of the clamping mechanism.

The rod is treated with hard chrome plating on the surface, which is resistant to wear and corrosion.

The second plate foot has an adjustable diagonal block structure, which is convenient to adjust after wear, thus extending the service life of the machine.

Automatic centralized lubrication is convenient for machine maintenance.

Adopting synchronous gear adjusting mode, automatic adjusting mode can be realized.

Clamping position ruler connected to the thrust seat, more convenient to adjust the mold protection position.

The optimized design of the machine connecting rod mechanism, the opening and closing die is smooth and fast, and the life is long.

Injection unit

Adopt short and powerful double cylinder injection system and high precision linear guide rail, with low inertia and high response injection mechanism, to ensure smooth injection action and fixed template without deformation, optimize the design of screw components, to achieve better plasticizing effect. Automatic cleaning, anti-salivation, anti-cold start delay and other functions to ensure efficient, simple and safe work.

Double injection transfer cylinder, improve injection stability.

Double parallel linear guide rail, improve injection stability and response speed.

High-speed hydraulic motor.

Closed circuit control of injection and holding pressure, precise control of back pressure.

Screw cylinder on the disassembly structure, easy to replace.

High-strength mechanical structure design to ensure lasting precision.

Low speed high torque hydraulic motor drive screw rotation, excellent plasticizing performance.

The optimized design of the screw has wide applicability of raw materials.

Hydraulic unit

Advanced hydraulic system design, through the pressure, flow proportional control to achieve rapid multi-stage pressure, speed switching, system configuration is reasonable, advanced, stable and reliable, noise less than 75dB, the whole series of machine adopts two-way cartridge valve system, catch the system flow and response speed, so that the whole machine performance to achieve the best.

The oil circuit system design of the large flow cartridge valve not only ensures the requirements of fast system response and small impact, but also reduces the pressure loss of the oil circuit.

Spiral flow cooler, high heat transfer efficiency, small pressure loss, to ensure the stable operation of the hydraulic system, improve the repeatability and product pass rate.

Low speed and high torque hydraulic motor drives the screw to meet the plasticizing requirements of various raw materials.

Electric control system

Huawei - More excellent operating performance, user-friendly operation interface, improve machine sensitivity and stability, online curve detection function and central connection management, rich SPC quality management interface, is definitely the best tool for you to create profits.
